cold heading machine
Model: ID 10 X190
Model ID 10 X 190
Forging Station (Nos.) 1
Max. Cut-off Dia.(mm) 10
Max. Cut-off Length (mm) 190
Static Die Ejection Length (mm) (K.O Stroke) 155
Dynamic Die Ejection Length (mm) 12
Shear Size (T X W X L mm) 19X45X113
Main Die Size.(mm) ?65X168
#1????2 Punch Die Holder Size ?48X120
Cut-off Die Size (mm)
?35X45Main Slider Stroke (mm) 220
Screw Size can be made??m????
Max. Length 150
Min. Length 40
Max.Output (Pcs./Min.) 60
Main Motor (Kw) 11(15 hp)
Oil Pump Motor(HP) 1/2
Weight (Kg) 6300
