PAM-TFA for CATIA V5

Die Face Design

Die Face Design and feasibility/formability simulation fully integrated into CATIA V5

ESI Group''s CATIA V5 PLM based metal forming portfolio provides die designers with a powerful set of engineering solutions which addresses design and manufacturing issues directly within a powerful generative modeling PLM environment:

PAM-TFA for CATIA V5 stands for Transparent Formability Analysis integrated into the CATIA V5 environment. It is a powerful ''inverse'' solver, offering up front part feasibility and part costing solutions.

PAM-DIEMAKER for CATIA V5 is a fully integrated workbench inside the CATIA V5 environment (including a seamless link to simulation) dedicated to die face design. It guides the user through the die face design process (tipping, binder design, addendum design, trimline development, ...) with powerful and trade-oriented functionalities, from upfront feasibility studies to full final validation.

KEY BENEFITS:

Super fast Die surface engineering based on B-spline geometry
Two operation modes: Product development (feasibility) or tooling
You work in CATIA with a CATIA database
You can use PAM-DIEMAKER or native CATIA functions
No more hold when you need to modify the part geometry
Fast and robust part replace
Direct link with PAM-STAMP and highly automated data transfer
Fastest solver in the market, for feasibility as well as formability (make the test!)
Best simulation quality in the market
