CPO-210D Hydraulic Press Plier
Scope: Power cable terminal crimping
Hydraulic crimping tool CPO-210D
1, the power cable wires connected with the hydraulic pressure is not easy to fall off and the heat.
2, two-speed unit will die quickly to the pressure to take over, Asia Relay rise and then automatically switches to low speed to complete the crimping process is both time and effort.
3, pressure junctions are free to rotate 180 • can work in narrow places.
4, built-in relief valve, when the pressure reaches the set maximum pressure relief automatically to prevent over-voltage tools.
5, CPO-210D standard point-die: 16,25,35,50,70,95,120,150,185,240
6, glass fiber insulation operation rod, to prevent accidental shock.
7, Package-one beautiful and practical use of plastic boxes.
Technical parameters:
Output: 12T
Crimping capacity :16-240 mm2
Stroke: 30mm
Size: 620 * 160 * 70mm
Weight: 6.5kg
|
|
|
|
|
